Description
Applications
• Used to attach and seal an industrial hose to a fitting such as a nipple
• Commonly used in automotive and agriculture industries
Features
• Includes t-bolts to ensure a tight seal between the hose and the fitting, preventing fluid from escaping
• Made from 304 stainless to improve corrosion resistance and working life
| Part | QFind | Description | Product | Finish | Size | Len |
|---|---|---|---|---|---|---|
| PHC44HTB19019 | HTB100 | W4/W4 HTB H/CLAMP:19.0X 17- 19 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 17-19 |
| PHC44HTB19022 | HTB101 | W4/W4 HTB H/CLAMP:19.0X 20- 22 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 20-22 |
| PHC44HTB19025 | HTB102 | W4/W4 HTB H/CLAMP:19.0X 23- 25 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 23-25 |
| PHC44HTB19028 | HTB103 | W4/W4 HTB H/CLAMP:19.0X 26- 28 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 26-28 |
| PHC44HTB19031 | HTB104 | W4/W4 HTB H/CLAMP:19.0X 29- 31 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 29-31 |
| PHC44HTB19035 | HTB105 | W4/W4 HTB H/CLAMP:19.0X 32- 35 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 32-35 |
| PHC44HTB19039 | HTB106 | W4/W4 HTB H/CLAMP:19.0X 36- 39 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 36-39 |
| PHC44HTB19043 | HTB107 | W4/W4 HTB H/CLAMP:19.0X 40- 43 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 19.0 | 40-43 |
| PHC44HTB22047 | HTB108 | W4/W4 HTB H/CLAMP:22.0X 44- 47 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 44-47 |
| PHC44HTB22051 | HTB109 | W4/W4 HTB H/CLAMP:22.0X 48- 51 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 48-51 |
| PHC44HTB22055 | HTB110 | W4/W4 HTB H/CLAMP:22.0X 52- 55 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 52-55 |
| PHC44HTB22059 | HTB111 | W4/W4 HTB H/CLAMP:22.0X 56- 59 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 56-59 |
| PHC44HTB22063 | HTB112 | W4/W4 HTB H/CLAMP:22.0X 60- 63 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 60-63 |
| PHC44HTB22067 | HTB113 | W4/W4 HTB H/CLAMP:22.0X 64- 67 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 64-67 |
| PHC44HTB22073 | HTB114 | W4/W4 HTB H/CLAMP:22.0X 68- 73 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 68-73 |
| PHC44HTB22079 | HTB115 | W4/W4 HTB H/CLAMP:22.0X 74- 79 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 22.0 | 74-79 |
| PHC44HTB25085 | HTB116 | W4/W4 HTB H/CLAMP:25.0X 80- 85 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 80-85 |
| PHC44HTB25091 | HTB117 | W4/W4 HTB H/CLAMP:25.0X 86- 91 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 86-91 |
| PHC44HTB25097 | HTB118 | W4/W4 HTB H/CLAMP:25.0X 92- 97 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 92-97 |
| PHC44HTB25103 | HTB119 | W4/W4 HTB H/CLAMP:25.0X 98-103 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 98-103 |
| PHC44HTB25112 | HTB120 | W4/W4 HTB H/CLAMP:25.0X104-112 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 104-112 |
| PHC44HTB25121 | HTB121 | W4/W4 HTB H/CLAMP:25.0X113-121 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 113-121 |
| PHC44HTB25130 | HTB122 | W4/W4 HTB H/CLAMP:25.0X122-130 | HOSE CLAMP HTB – H/DUTY | W4 (304) STAINLESS | 25.0 | 122-130 |
Additional Information
| Size | 19.0X 17-19mm, 19.0X 20-22mm, 19.0X 23-25mm, 19.0X 26-28mm, 19.0X 29-31mm, 19.0X 32-35mm, 19.0X 36-39mm, 19.0X 40-43mm, 22.0X 44-47mm, 22.0X 48-51mm, 22.0X 52-55mm, 22.0X 56-59mm, 22.0X 60-63mm, 22.0X 64-67mm, 22.0X 68-73mm, 22.0X 74-79mm, 25.0X 80-85mm, 25.0X 86-91mm, 25.0X 92-97mm, 25.0X 98-103mm, 25.0X104-112mm, 25.0X113-121mm, 25.0X122-130mm |
|---|
